A safer, more ergonomic way to lift and position heavy SUV and light-truck wheels
| Quick answer: The K&L Supply K2600 is a compact, mobile tire lift for raising, supporting, and positioning wheels during removal and installation. The dealer portal lists a 200 lb capacity and a 0–50 in. lifting range. It also lists a 6-second lift time and a 5-second lowering time. Wheel-support forks help technicians align heavy SUV and light-truck wheel assemblies. This design reduces repetitive lifting and awkward handling. |
Before Tire Lifts: Heavy Wheels, Repetitive Lifting, and Awkward Alignment
Wheel service often requires technicians to lift, carry, rotate, and hold wheel assemblies while aligning them with the hub. The work becomes harder as wheel-and-tire packages grow larger, wider, and heavier. This is especially true for SUVs, pickups, and light trucks.
Traditional methods may require technicians to lift a wheel from the floor and balance it on a knee or foot. A basic tire cart can move the wheel, but it may not raise it to hub height. The wheel’s weight and the need for precise alignment can slow the job. These factors can also place extra strain on the technician.
A tire lift supports the wheel from below and simplifies the process. The technician can roll the lift into position and raise the wheel to the required height. Small, controlled adjustments help align the wheel before removal or installation.
What Is a Tire Lift?
A tire lift is a mobile shop device that raises and positions complete wheel-and-tire assemblies. It is especially useful when a wheel is too heavy or awkward to handle comfortably by hand. Common applications include:
- Removing and installing SUV and light-truck wheels
- Positioning heavy wheel assemblies at the vehicle hub
- Supporting wheels during brake, suspension, and tire service
- Moving wheel assemblies within a service bay
A standard tire cart mainly moves wheels around the shop. A tire lift also provides vertical positioning. The wheel stays supported while the technician aligns its center and lug holes with the hub.
Why Repair Shops Need a Modern Tire Lift
1. Less Repetitive Manual Lifting
Large wheel-and-tire assemblies are difficult to lift from the floor and hold at hub height. The K2600 handles much of this movement, reducing repeated bending and unsupported holding.
2. More Controlled Wheel Positioning
Wheel installation requires accurate alignment as well as lifting. The K2600 supports the wheel on its forks while the technician adjusts the height. This provides a stable starting point at the hub.
3. A Faster, More Consistent Workflow
The K2600 has a listed 6-second lift time and 5-second lowering time. These speeds help technicians move efficiently between floor level and service height. Less repeated lifting and resetting can also make the process more consistent.
4. Compact Mobility for Busy Service Bays
The K2600 measures 30.5 in. long and 31 in. wide, so it can fit within many service bays without permanent installation. At 154 lb, it is built for professional use and can be moved between work areas.
K2600 Features and Specifications
The K2600 is a purpose-built wheel-handling tool for professional automotive service shops.
| Specification | K2600 Details |
| Maximum capacity | 264 lb |
| Lifting range | 0–50 in. |
| Lifting speed | 6 seconds |
| Lowering speed | 5 seconds |
| Fork length | 17.5 in. |
| Fork width | 22.05 in. |
| Overall height | 61 in. |
| Overall width | 31 in. |
| Overall length | 30.5 in. |
| Equipment weight | 154 lb |
Designed for Heavier SUV and Light-Truck Wheels
Wheel and tire packages have grown larger on many modern vehicles. Wider tires and heavier wheel designs can make routine service more demanding. K&L designed the K2600 for heavier SUV and light-truck applications. In these jobs, lifting and alignment are often the most difficult steps.
The K2600 has a listed 200 lb capacity. Its forks measure 17.5 in. long by 22.05 in. wide. This supported platform helps technicians handle large wheel assemblies. Before lifting, confirm the complete wheel-and-tire weight. Center the load on the forks and follow all product instructions.
K2600 vs. Traditional Tire Handling Methods
Manual lifting and tire carts still have a place in the shop. However, they handle only part of the wheel-service process. The K2600 combines transport, vertical lifting, support, and positioning in one mobile unit.
| Comparison | Manual Handling | Tire Cart / Dolly | K2600 Tire Lift |
| Primary function | Lift and carry by hand | Transport a wheel across the shop | Lift, support, and position a wheel at service height |
| Vertical positioning | Technician supplies the lifting force | Little or no powered height adjustment | 0–50 in. lifting range |
| Alignment at the hub | Manual balancing and repeated adjustments | Wheel still needs to be lifted from the cart | Forks support the wheel while height is adjusted |
| Typical application | Lighter wheels or occasional handling | Moving wheels and tires between work areas | Repeated SUV and light-truck wheel service |
| Technician effort | Highest manual effort | Reduces carrying but not installation lifting | Designed to reduce repetitive lifting and awkward positioning |
Watch the K2600 Tire Lift in Action
The overview and demonstration video shows the K2600 as a complete wheel-handling solution. A separate assembly video explains the setup process. Shops can review both videos before placing the lift into service.
Why Choose K&L Supply?
K&L Supply began in 1968 as a motorcycle repair and service shop in Santa Clara, California. It later expanded into parts, specialty tools, and professional equipment for powersports and automotive service. The K2600 continues this shop-focused approach by making heavy wheel handling safer and easier.
Read the K&L Supply company story
Frequently Asked Questions About the K2600
1. What is the K2600 Tire Lift used for?
The K2600 lifts, supports, moves, and positions complete wheel-and-tire assemblies. It helps technicians move a wheel from the floor to the vehicle hub with less manual lifting.
2. How much weight can the K2600 lift?
The K&L dealer portal lists a maximum capacity of 200 lb. Confirm the complete wheel-and-tire assembly weight and follow all operating instructions before use.
3. How high does the K2600 lift?
The listed lifting range is 0–50 in. The dealer portal also lists a 6-second lift time and a 5-second lowering time.
4. Is the K2600 suitable for SUV and light-truck wheels?
Yes. K&L designed the K2600 for heavier SUV and light-truck tires. Keep each wheel assembly within the listed capacity and centered on the forks.
5. Does the K2600 replace a tire changer or wheel balancer?
No. Tire changers remove tires from wheels, and wheel balancers correct imbalance. The K2600 moves and positions the complete wheel-and-tire assembly between the floor and the vehicle hub.
Make Heavy Wheel Service Easier on Your Technicians
SUVs and light trucks often use large, heavy wheel-and-tire packages. The K&L Supply K2600 helps shops lift, move, and align these assemblies. Its 200 lb capacity, 0–50 in. lifting range, mobile design, and positioning forks support a more controlled workflow with less manual handling.
Explore the K2600: View product details | Watch the demonstration | Watch assembly
